Configurations

View materials:

  • Fixing to Concrete
  • Fixing to Timber
  • Fixing to Ground

Applications

  • Portable Buildings
    Portable Buildings
  • Accessibilty
    Accessibilty
  • Industrial Buildings
    Industrial Buildings
  • Site Offices
    Site Offices

Benefits

Off-site Manufactured Solution

Manufacturing offsite is the way of the future. It not only saves waste and greatly speeds up the completion of projects, but allows great quality, control and consistency.

BENEFITS FOR BUILDERS

  • Reduces time from the building being completed to the stairs, ramps and decks being completed.
  • Reduces the need for complex, on site measuring.
  • Speeds up the manufacture and delivery process.
  • Produced offsite, as a kitset which turns up ready to go and installed within a couple of days.
  • Adjustable and compatible which gives it flexibility to fit a wide range of sites.
  • Flexible Cladding options. Tie into existing look and feel.
  • Supplied complete with all fixings, boards and clear easy to follow installation instructions.
  • Designed for simple assembly  – don’t need skilled staff for install.

BENEFITS FOR SPECIFIERS

  • Pre-engineered system which guarantees a compliant access system to the New Zealand Building Code (NZBC).
  • Supplied with an engineering producer statement.
  • Easy to specify – Downloadable Revit Files available here
  • Masterspec worksection coming…

Compliance

Moddex Ezibilt™ system is designed and manufactured in accordance with the following loading standards:

  • AS/NZS1170.0
  • AS/NZS1170.1
  • AS/NZS1170.2
  • AS/NZS1170.3
  • AS/NZS1170.5
  • AS1428 Access Routes
  • NZBC – NZ Building Code

Live Load allowance of 2.5kPa (5.0 kPa or 1.8 kN achievable with correct foundation)

Maximum height of 0.6m without bracing, up to 4m with bracing

Maximum wind zone of “Very High”

Compatible with all Moddex handrail and balustrade systems

Supplied with Reg. 126 Certificate & PS1.
